Horizontal Directional Drilling Locating System

Mag X COR System

Drill with Ease

The Mag X COR provides you with the core features you want and pairs it with the power you have come to know from our locators.

Core Features

  • Simplicity Paired with Power
    • Premium HDD locator experience in a simplified package
    • Stand-up receiver with 4” reflective LCD display
    • Color 7” Android-based touch screen drill display
    • Tracking-on-the-Fly for fast, accurate, everyday locating
  • Built-in Data Logging
    • Simplified one-touch logging integrated into the remote drill display
    • Rodwise and chart views with the ability to edit and add utility crossings
    • Easily emailed directly from the display and synced to the UMmaps web portal

Starting at

$19,000

Mag X COR Receiver
1 × Mag X COR Receiver
Mag X Display for Horizontal Directional Drilling
1 × Mag X Display
Echo 50XF Transmitter HDD Locating System Underground Magnetics
2 × Echo 50XF Transmitter
Mag X/9 Hard Carrying Case
1 × Mag X/9 Hard Carrying Case

Specifications

Weight 8.5 lbs
Dimensions 29 × 9 × 13 in
Antenna

Faraday Shielded 3D Antennas

Compatible Transmitter

Echo 50, Echo 50XF, Echo X-Mini, Echo ST

System Frequency

16 Frequencies, .325kHz – 41kHz

Temperature Range

-4°F to 140°F (-20°C to 60°C)

Radio Frequency

915 MHz (US) / 433MHz (EU) / 867 MHz (IN)

Telemetry

4 Radio Channels with range up to 3,000 ft (900m)

Power

Rechargable Lithium Battery 12.5V

Battery Life

50 hours

Waterproof

IP65

Spec Sheet

Manual
